Name: CNC Plasma Cutting Machine For Box Beam Production Line Plasma Cutting Machine
Brand: FRIENDSHIP MACHINERY
Price: 1 USD

Brand Name : FRIENDSHIP MACHINERY

Model Number : GSD

Certification : CE, ISO

Place of Origin : CHINA

MOQ : 1

Delivery Time : 30 working days

Packaging Details : Standard Packing

Control way : CNC

Cutting method : Plasma and Flame

CNC system : Beijing Start or Shanghai Jiaoda

Plasma system : Huayuan LGK200

Servo motor : Panasonic, Japan

Warranty : 1 Year

Contact Now

Technical Specification
Model	CNC
Machine dimension (mm)	Maximum 12 meter in width and not limited in length
Effective processing area (mm)	1 meter less in width and 2 meter less in length than machine size
Suggested cutting thickness (mm)	Stainless steel:1-50mm and Carbon steel:6-160mm
Drilling capacity (mm)	Maximum 140mm in depth and 35mm in diameter
Drilling power	8Kw (25hp) 1Kw=1.36PS=1.34HP
Drilling feed	10m/min (400ipm)
Drilling torque	200 N.M. (150 ft-lb)
Borehole pressure	11000 N (2500 lbf)
Cutting Speed (mm/min)	50-9000
Running speed (mm/min)	12000
Cutting Mode	Oxy-fuel/ Plasma/ High definition plasma/ Laser
Drive mode	Servo motor, Dual-side
Guide track	Straight ball-guide
Cutting Torch Number	Customer specified
Driving Motor	Panasonic from Japan
NC Controller	Micro EDGE pro, Shanghai KP, SJTU-SK
Plasma Power	Victory (Thermadyne), Kjellberg, Hypertherm, JIAXIN LGK
Programming software	FASTCAM
Gearbox	SEW or Neugart from Germany
Working temperature	- 10°C -45°C
Humidity	<90%, no condensation
Surroundings	Ventilation, vibrationless
Power voltage	3×380V±10% 50Hz/ according to user's local condition
Operation language	Multilingual and English available
Powder marking	available
Under water cutting	available
Beveling torch	available
Strip cutting torch	available
Heating and cooling system	available
Integration dust extraction	available
Thin plate processing device	available
