16mm Diameter Screw Threading CNC Drilling Machine

Name: 16mm Diameter Screw Threading CNC Drilling Machine
Brand: FRIENDSHIP MACHINERY
Price: 1 USD

Brand Name : FRIENDSHIP MACHINERY

Model Number : GS SERIES

Certification : CE, ISO

Place of Origin : CHINA

DIameter : 16-40mm

Motor : 4KW

Voltage : 380V/ 50HZ

Warranty : 1 year

Speed : 60rpm

Machine name : Steel Rod threading machine

Contact Now

Steel Rod And Screw Threading Machine

CNC Drilling Machine For Metal Steel Rebar

Screw Bolt Threading machine

1. Simple introduction

It is designed for threading 5-42mm diameter in cold processing, with spiral threading wheel is possible to processing fixed thread/ wire boom thread. It is welded by steel plate, and with a high strength structure, easy to operate.

2. Technical parameter

No.	Item		Specification
1	Maximum threading diameter		5-42mm
2	Threading wheel	Outer diameter	120-170mm
		Hole diameter	54mm
		Section width	100mm
3	Maximum threading capacity		150KN
4	Main axis inclination angle		±5°
5	Main axis rotation		37/ 46/ 63/ 79rpm
6	Mechanical transmission motor		5.5KW
7	Hydraulic transmission motor		2.2KW
8	Hydraulic auto feeding time/ cease time		0.1-99.9s
9	Cooling pump		90W
10	Dimension		150015501350
11	Weight		1800kgs

16mm Diameter Screw Threading CNC Drilling Machine
